Ports and operating elements
Rear
1 82 3 4
5 6
7
14 13 3 11 12 11 910
1 = Monitor s ocket (op
tional)
2 = Eye for lead-seal or padlock
(diameter 6 mm)
3 = Serial port (op
tional, above: 2nd optional)
4=4slotsforlow-profile boards or port
expansions (VGA, parallel port, eSATA)
5 = LAN port
6 = PS/2 mouse port
7 = Audio input (
Line In), light blue
8 = Security lock devi
ce
9 = Audio output (Line Out), light green
10 = PS/2 keyboard por
t
11 = USB ports
12 = Display ports (
above: 2nd optional)
13 = DVI-D monitor port
14 = Alternating v
oltage sock et (AC IN)
10 Fujitsu
