System expansions
Mainboard expansions
Details on how to upgrade the main memory or the processor of your device
can be found in the manual for the mainboard.
UpgradesLithium ba tteryProcessorMainmemoryM ainboard
Upgrading main memory
► Remove the casing cover (see Chapter "Re moving the casi ng cover", Page 36).
Mainmemory,
► Upgrade the memory according to the description in the manual for the mainboard.
► Fit the casing cover back onto the casing (see Chapter "
Reat taching the cas ing cover.", Pag e 37).
Processor, replacing
► Remove the casing cover
(see Chapter "
Removing th e casing cover", Page 36).
Proce ssor,re placi ng
► Remove the heat sink (see "Removing the heat sink", Page 71).
► Upgrade the processo
r according to the description in the manual for the mainboard.
► Reinstall the heat sink (see "
Installing the he at sink", Page 73).
► Fit the casing cover
back onto the casing (see Chap ter "
Reat taching the cas ing cover.", Pag e 37).
74 Fujitsu
