System expansions
Installing a slimline drive
• The drive plate is attached t o the slimline drive (see chapte r "Installing t he
drive plate for the slimline drive", Page 42).
• A suitable d rive cover is mounte d (see chapter "
Changing the drive cover", Page 39).
1
► Slide the sliml
ine drive into its bay in the direction of the arrow (1) until it engages in place.
► Connect the cables to the slimline drive and to the mainboard. Ma ke sure the polarity is correct.
► Fit the casing
cover back onto the casing (see Chapter "
Reat taching the cas ing cover.", Pag e 37).
If n ecessary,
you must adjust the entry for the drive accordingly in the BIOS Setup.
44 Fujitsu
