System expan sio ns
Installing and removing heat si
nks
Removing the hea t sink
► Remove the casing cover (see Chapter "Removin g the casi ng cover", Page 36).
1
2
a
► Pull the catch of t he hood in the direction of the arrow (1) (identified with the label "PULL").
► Slightly tilt t
he cowl and lift it out of the casing (2). In doing so, take care that
the pins (a) rel
ease from the openings on th e casing.
4
3
► Undo
the screws on the he at sink (3).
► Lift the heat sink out of the casing (4).
Fujitsu 71
