Getting s tarted
Setting up the device
Videoworks tationErgonomicDevice,
When setting u p your device, please read the recommendations and
safety notes in the "Safety/regulations" manua l.
We recommend that you place your device on a surface with good anti-slip qualities.
In view of th e m ultitude of different finishes and varnishes used on furn iture, it is
possible that the rub ber feet will mark the surface they stand on.
Depending on the location of your device, bothersome vibrations and noises may
occur. To prevent this, a distance of at least 10 mm / 0.39 in should be maintained
from other devices on casing sides without ventilation s urfaces.
In order to avoid overheating, do not cove r the ventilation areas
on the monitor o r the device.
A minimum distance of 2 00 mm / 7.87 in from the device must be
observed for ventilation area s.
Do not stack several devices on top of each other.
Do not expose the device to extreme ambient conditions (see "
Technical spe cification",
Pag e 76, "Ambient conditions"). Protect the device against dust, humidity and heat.
Operating po s iti
on
You can use th e de
vice in a vertical or horizontal operating position.
With th e aid of s
uitable feet, it is possible to use the device in a vertical ope rating position
(see "
Verti cal
operating position with feet (optional)", Page 16).
Vertical operating position with feet (optional)
Use the optional feet when you wish to use the device in the vertical operating position.
The set-up direction is compulsory: The ON/OFF switch must be at
the top to ensure sufficient ventilation.
You must rem ove the feet again to be able to open the device.
VerticaloperatingpositionOperatingpos ition,verticalBasefeetSidecover
Proceed as follows to opera te the device in the vertical operating position with the feet:
► If necessary, disconn ect the cables connected to the device.
16 Fujitsu
