System expan sio ns
Removing an M.2 module
► Remove the casing c over (see chapter " Removing the casing cover", P age 36).
► Fold out the drive cage (see chapter "
Opening the drive cage", Pa ge 4 7).
a
b
1
2
► Undo the s crew (1)
.
► Pull the M.2 module (b) slightly at an angle in th e direction of the arrow (2) and out
of the slot (a) on the mainboard and remove it from the casing.
► Fold the drive
cage into the closed position again (see chapter "
Closing the drive ca ge", Page 48).
► Fit the casing cover onto the casing again (see chapter "
Reat taching the casing cover.", Pa ge 37).
If necessary, you must adjust the entry for the M.2 mod ule accordingly in the BIOS Setup.
Fujitsu 61
