System expan sio ns
Installing and removing 2½ inch drives in
a 3½ inch adapter
You can install two non-accessible 2½ inch drives with a 3½ inch adapter in the lower and middle bays.
Installing 2½ inch drives in a 3½ inch adapter
EasyChange rails for both drives are in the adapter.
a
► Fasten the EasyChange rails to the side of the first drive by inserting each pin of the
EasyChange rail in the c orrespo ndin g holes on the drive. In doing so, make sure that
the ports on the drive are located at the rear as shown (a).
► Repeat the step for the second drive.
Fujitsu 49
