System expan sio ns
Opening a nd closing the drive cage
To be able to install and remove drives in the m iddle and lower bays, it is
necessary to fold the drive cage upwards.
Opening the drive cage
► Remove the casing c over (see chapter " Removing the casing cover", P age 36).
a
1
2
► Press the rele ase (a) in the direction of the arrow (1 ).
► Fold the drive cage fully open (2 ) until it locks in place.
Fujitsu 47
