System expan sio ns
Do not discard the filler panel. Depending on the desired configuration level, you must
reinstall the filler panel for cooling, protection against fire and in order to comply with EMC
(electromagnetic compatibility) regulations (see ""
Removing a slimline drive", Page 45").
2
b
b
a
a
► Insert the new drive c over into the casing cover from the front. In doing so, make
sure th at all the inner catches that are presen t engage (a, b).
► Change the desired drives as required, as described in the corresponding chapter.
► Fit the casing cover onto the casing again (see chapter "
Reat taching the casing cover.", Pa ge 37).
Fujitsu 41
