System expansions
The screw positions are different for non-accessible drives and accessible drives:
• sheet metal stamping 1 (in illustration: b) valid for accessible
drives (Multicard/SmartCard reader).
• sheet metal stamping 2 (in illustration a) valid fo r non-accessible
drives (H DDn/SSDn, also in adapter).
► Secure the drive with the scr
ews ( a or b, depending on the type of drive).
► When installing a 3½ inch hard disk: Connect the cables to the drive.
Make sure the polarity is correct.
► Connect the other end of t
he cable to t he corresponding USB port or SATA port of the mainboard.
► Fold the drive cage into the closed position again ( see chap ter "
Closing the drive cage", Page 4 8).
► Fit the casing cover ont
o the casing again (see chapter "
Reat taching the casing cover.", Pag e 37).
If ne cessary, you must
adjust the entry for the drive accordingly in the BIOS Setup.
