Fujitsu ETERNUS CS800 Getting Started Guide

CS800 Basic Storage Module Hardware Description
70 U41842-J-Z125-1-76
Front View – Panel Features and Indicators
Figure 45 and figure 46 show the front side of the DX80 basic storage component with and
without cover. The DX80 contains twelve (3 x 4) 3.5“ SAS hard disk drives.
Figure 45: Front View of DX80 Storage Module with Cover
Figure 46: Front View of DX80 Storage Module without Cover
Figure 47 shows the indicators on the left side. For information about the HDD indicators
see "Hard Drive Carrier Indicators".
Figure 47: Indicators and Switches on the Front Side of DX80 (with Cover and with Front Cover Removed)
1
2
3
4
5
6
1
2
3
