Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
▶
"Removing the air duct" on page 63.
Removing the defective heat sink
▶
Remove the CPU heat sink, see "Removing the heat sink" on page 245.
▶
Remove the residual thermal paste from the CPU surface.
▶
Clean the CPU surface using a lint-free cloth.
Installing the new heat sink
▶
Remove the protective cover on the underside of the new heat sink.
CAUTION
▶
Do not touch the thermal paste on the underside of the heat sink.
▶
Install the CPU heat sink, see "Installing the heat sink" on page 252.
Concluding steps
▶
"Installing the air duct" on page 64.
▶
"Reassembling" on page 52.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 58.
Processor (CPU)
254 Upgrade and Maintenance Manual RX1330 M4
