Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

▶
Remove all memory modules, see "Removing memory modules" on
page 238.
Before removing the memory modules, take a note on the installation
slot number for each memory module. Ensure that you install the
memory modules in the slot they were located before the
replacement.
▶
Remove all expansion cards, see "Expansion cards and backup units" on
page 183.
Before removing the expansion cards, take a note on the installation
slot number for each card. Ensure that you install the card in the slot
it was located before the replacement.
▶
If applicable, remove the iRMC microSD card, see "Removing the iRMC
microSD card" on page 307
.
▶
If applicable, remove all M.2 SSDs, see "Removing an M.2 SSD" on
page 314.
▶
If applicable, remove the Dual microSD 64GB Enterprise, see "Removing
the Dual microSD 64GB Enterprise" on page 319.
Removing the defective system board
▶
Disconnect all cables from the system board.
System board and components
328 Upgrade and Maintenance Manual RX1330 M4

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
