PRIMERGY RX200 S2 User’s Guide
Installing Internal Options
7
■ Notes on Installation
● Drivers
For expansion card drivers, refer to "2.3.5 Expansion Cards Supported by ServerStart" (pg.48).
● Notes on Each Card
For notes of specific expansion cards, refer to the manuals supplied with the card and the notes provided
with the server. Also, check the following for respective expansion cards.
● SCSI Card/RAID Card
• Connection of a SCSI device
• For optional device connection using a SCSI or RAID card, refer to "7.10 Connection of Optional
Devices" (pg.201).
• Connect a SCSI device supported by this server to the SCSI or RAID card.
Operations of unsupported SCSI devices are not guaranteed.
● BIOS Settings
The expansion ROM for expansion cards is disabled on this server. To configure an expansion card, the
expansion ROM must be temporarily enabled in the BIOS Setup Utility. The configuration procedures
are as follows.
1 Enable the expansion ROM of the slot for the expansion card to be configured.
Start up the BIOS Setup Utility and select the "■ PCI SLOTS Configuration Submenu"
(pg.218) from the [Advanced] menu. Change [Option ROM Scan] from [Disabled] to
[Enabled].
2 From the "8.2.17 Exit Menu" (pg.232), select [Save Changes & Exit] to exit
the BIOS Setup Utility.
3 Restart the server and configure the expansion card in POST.
4 After configuring the expansion card, start up the BIOS Setup Utility again and
return the setting you have changed in Step 1 to the original setting.

Fujitsu PRIMERGY RX200 S2 Specifications

General

Chipset	Intel 5000P
Network	Dual Gigabit Ethernet
Operating System Support	Windows Server, Linux
Processor	Intel Xeon processors
Memory Slots	8 x DIMM
RAID Support	RAID 0, 1
Power Supply	Redundant power supply
Form Factor	1U rack server
