25
PRIMERGY RX200 S2 User’s Guide
1
Overview
1.3.3 Server (Internal)
a PCI slot
Contains extension cards that enhance the server functions. Expansion cards with the PCI bus
interface can be installed in the PCI slots.
b Memory slot
Contains memory.
c CPU socket
Install the CPU. One CPU is installed by default. Up to two CPUs can be installed.
d System fan
Contact an listed in the "Contact Information" of the "Start Guide" for the system fan
replacement.
a
b
c
d
