Chapter 7 Installing Internal Options
7.6.2 How to Install an Internal CD-ROM Drive Unit
This section explains how to install an internal CD-ROM drive unit.
1 Turn the power off and remove the top cover.
"7.2 Removing and Attaching the Top Cover" (pg.166)
2 Touch a metal part of the server to discharge static electricity.
3 Release the latches on the top of the CD-ROM drive bay and remove the
dummy CD-ROM.
4 Insert the internal CD-ROM drive unit into the CD-ROM drive bay.
Press two latches
with a driver
Dummy CD-ROM
Internal CD-ROM drive unit
To Next Page
