Fujitsu PRIMERGY RX200 S2 User Manual

241
PRIMERGY RX200 S2 User’s Guide
8
Hardware Configuration/Utilities
8.3.6 Device Properties Submenu
Configures devices connected to SCSI adapters.
table: Items on the Device Properties Submenu
Item Setting Description
Restore Defaults -
The server does not support this.
MT/Sec • 0
•5
•10
•20
•40
•80
• 160 (at the time of
purchase)
Sets the maximum transfer rate the host adapter
supports.
MB/Sec - Displays the maximum transfer speed the host
adapter supports.
Data Width 16 (Fixed parameter) Sets the maximum transfer width the host adapter
supports.
Scan ID • Yes (at the time of
purchase)
•No
Sets whether or not to scan devices.
Scan LUNs>0 Yes (Fixed parameter) Sets whether or not to scan LUNs.
Disconnect On (Fixed parameter) Sets whether or not the host adapter disconnects
SCSI devices from the SCSI bus.
SCSI Timeout 10 (Fixed parameter) Sets the SCSI timeout time (seconds).
Queue Tags On (Fixed parameter) Sets whether or not to support tagged command
queues.
LSI Logic MPT SCSI Setup Utility Version MPTBIOS-IMx.xx.xx
Esc=Abort/Exit ArrowKeys=Select Item -/+=Change[Item]
Home/End=Select Item Enter=Execute<Item>
SCSI
ID
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Mt/Sec
[160]
[160]
[160]
[160]
[160]
[160]
[160]
[160]
[160]
[160]
[160]
[160]
[160]
[160]
[160]
[160]
Device Properties
Scan
LUNs>0
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
Dis-
connect
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
SCSI
TimeOut
< 10>
< 10>
< 10>
< 10>
< 10>
< 10>
< 10>
< 10>
< 10>
< 10>
< 10>
< 10>
< 10>
< 10>
< 10>
< 10>
Queue
Tags
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
[On]
Device
Identifer
-
1020/1030
SDR CEM318
Restore
Defaults
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
<Defaults>
MB/Sec
320
320
320
320
320
320
320
320
320
320
320
320
320
320
320
320
Data
Width
[16]
[16]
[16]
[16]
[16]
[16]
[16]
[16]
[16]
[16]
[16]
[16]
[16]
[16]
[16]
[16]
Scan
ID
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
[Yes]
