Fujitsu PRIMERGY RX200 S2 User Manual

298
C Remote Control Function and Console Redirection
C.1 Connecting the Server to a PC
Connect the server to a PC using a cross cable.
 In the BIOS Setup Utility, perform the following setting.
• On the [Peripheral Configuration] submenu of the [Advanced] menu, change [Serial Multiplexer] to
[BMC].
"8.2.6 Peripheral Configuration Submenu" (pg.216)
C.2 Operating the Remote Control Utility
The following explains how to operate the Remote Control Utility
■ Connection
1 Connect the serial port to the management terminal using an RS-232C cross
cable.
2 Establish connection using the terminal software.
■ Operation on the Server
Perform the following operations in the terminal software on the management terminal.
1 Establish connection using the terminal software and press the [Enter] key.
The following message appears.
Login>
The server (rear)
Personal computer
Cross cable
Serial port
Serial port

Fujitsu PRIMERGY RX200 S2 Specifications

General

Chipset	Intel 5000P
Network	Dual Gigabit Ethernet
Operating System Support	Windows Server, Linux
Processor	Intel Xeon processors
Memory Slots	8 x DIMM
RAID Support	RAID 0, 1
Power Supply	Redundant power supply
Form Factor	1U rack server
