PRIMERGY RX200 S2 User’s Guide
Installing Internal Options
7
7.3 Installing a CPU
The server can have up to two CPUs by adding an optional CPU.
7.3.1 Where to Install CPUs
CPU socket 0 is installed with a CPU by default. Install an additional CPU in CPU socket 1.
• Before installation or removal, turn off the server and all peripheral devices.
Also unplug all power cables from the server ("1.4.3 Turning Off the Server"
(pg.32)).
Failure to do so may cause electric shock or device failures.
• Do not install unauthorized third party CPUs. Doing so may cause failures.
• Do not use CPUs that differ in frequency or cache size. The system will not
start up.
• The circuit boards and soldered parts of internal options are exposed. They
can be damaged by static electricity.
Before handling them, first touch a metal part of the server to discharge static
electricity.
• Do not touch the circuitry on boards or soldered parts. Hold the metallic areas
or the edges of the circuit boards.
CPU
Socket 1
CPU
Socket 0
(Standard)
[Front]

Fujitsu PRIMERGY RX200 S2 Specifications

General

Chipset	Intel 5000P
Network	Dual Gigabit Ethernet
Operating System Support	Windows Server, Linux
Processor	Intel Xeon processors
Memory Slots	8 x DIMM
RAID Support	RAID 0, 1
Power Supply	Redundant power supply
Form Factor	1U rack server
