Chapter 1 Overview
1.3.4 Baseboard
a Memory slot
Contains memory. One memory bank consists of Slots A and B on this server. Be sure to install a
pair of memory modules.
b CPU socket 0
c CPU socket 1
Install the CPU.
d Fan board connector
e Power supply connector
f IDE connector for CD-ROM drive
An IDE cable for the optional CD-ROM drive is plugged in.
g Floppy disk drive connector
h JP7
i JP9
j SCSI connector
a
[Rear]
b
c
f
g
h
i
j
e
d
k
l
m
[Front]

Fujitsu PRIMERGY RX200 S2 Specifications

General

Chipset	Intel 5000P
Network	Dual Gigabit Ethernet
Operating System Support	Windows Server, Linux
Processor	Intel Xeon processors
Memory Slots	8 x DIMM
RAID Support	RAID 0, 1
Power Supply	Redundant power supply
Form Factor	1U rack server
