27
PRIMERGY RX200 S2 User’s Guide
1
Overview
k Internal power connector
An internal power supply cable is plugged in when a remote service board is installed.For more
details, refer to "
● Remote Service Board" (pg.182) in "7.5.2 Installable Expansion Cards and
Notes".
l Server control connector
A server control cable is plugged in when a remote service board is installed. For more details,
refer to "
● Remote Service Board" (pg.182) in "7.5.2 Installable Expansion Cards and Notes".
m Card locking frame connector
An expansion card locking frame is installed.
