Fujitsu PRIMERGY RX200 S2 User Manual

199
PRIMERGY RX200 S2 User’s Guide
Installing Internal Options
7
7.8.4 Replacing a Power Supply Unit when the Redundant
Function is Enabled
When the system power supply redundant function is enabled, a failed power supply unit can be
replaced without turning off the server.
After removing the power supply unit, be sure to install a new unit.
■ Power Supply Unit LED Status
■ Replacing the Power Supply Unit
1 Remove the power cable from the failed power supply unit.
2 Remove the failed power supply unit.
"■ How to Remove the Power Supply Unit" (pg.198)
3 Install the new power supply unit.
4 Plug the power cable into the inlet of the new power supply unit.
Power supply unit LED
Green On: The unit is operating normally
Amber On: An AC power supply is connected
or an error is detected in the
power supply unit

Fujitsu PRIMERGY RX200 S2 Specifications

General

Chipset	Intel 5000P
Network	Dual Gigabit Ethernet
Operating System Support	Windows Server, Linux
Processor	Intel Xeon processors
Memory Slots	8 x DIMM
RAID Support	RAID 0, 1
Power Supply	Redundant power supply
Form Factor	1U rack server
