Fujitsu PRIMERGY RX200 S2 User Manual

195
PRIMERGY RX200 S2 User’s Guide
Installing Internal Options
7
5 Install a new internal hard disk unit or a dummy unit.
"7.7.3 How to Install an Internal Hard Disk Unit" (pg.193)
■ Replacing the Failed Internal Hard Disk Unit
When an array system (RAID1) is configured with the onboard SCSI array controller on this server, a
failed hard disk unit can be replaced and restoration can be performed without turning off the server and
peripheral devices (hot swappable/hot pluggable).
For details on the array system, refer to "Onboard SCSI RAID User's Guide".
The following is an outline of the procedure for replacing a failed internal hard disk unit.
1 Check the hard disk unit failure LED on each bay.
2 Touch a metal part of the server to discharge static electricity.
3 Move the handle on the failed hard disk unit up and pull it a little towards you.
4 Wait for approximately 60 seconds (until the hard disk stops rotating) and pull
out the failed hard disk unit.
5 Install a new internal hard disk unit.
6 Rebuild the new internal hard disk unit.
For the rebuild procedure, refer to "Onboard SCSI RAID User's Guide".

Fujitsu PRIMERGY RX200 S2 Specifications

General

Chipset	Intel 5000P
Network	Dual Gigabit Ethernet
Operating System Support	Windows Server, Linux
Processor	Intel Xeon processors
Memory Slots	8 x DIMM
RAID Support	RAID 0, 1
Power Supply	Redundant power supply
Form Factor	1U rack server
