Fujitsu PRIMERGY RX200 S2 User Manual

242
Chapter 8 Hardware Configuration/Utilities
8.3.7 RAID Properties Submenu
Sets an array configured with the onboard SCSI array controller.
table: Items on the RAID Properties Submenu
Item Setting Contents
Array Disk? • Yes (array type/Linux array
type)
• No (other types than array
type/Linux array type)
Sets whether or not the hard disk unit configures a
disk array.
Hot Spare No (Fixed parameter) The server does not support this.
Status - Displays the hard disk status when a disk array is
configured.
• [Primary] or [OK]
Indicates that the hard disk unit is operating
normally.
• Failed
Indicates that the hard disk unit has failed.
• Out of Sync
Indicates that the hard disk unit being rebuilt.
• Missing
Indicates that the hard disk unit is not installed or
recognized.
Size (MB) - Indicates the hard disk capacity.
LSI Logic MPT SCSI Setup Utility Version MPTBIOS-IMx.xx.xx
Esc=Abort/Exit ArrowKeys=Select Item -/+=Change[Item]
Home/End=Select Item Enter=Execute<Item>
SCSI
ID
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Array
DISK?
[No]
[No]
[No]
[No]
[No]
[No]
[No]
[No]
[No]
[No]
[No]
[No]
[No]
[No]
[No]
[No]
RAID Properties Array: SCSI ID: Size(MB):
Hot
Spare
[No]
[-]
[-]
[-]
[-]
[-]
[-]
[-]
[-]
[-]
[-]
[-]
[-]
[-]
[-]
[-]
Status Predict
Failure
Size
(MB)
Device Identifier
-
1020/1030
SDR CEM318
***MB
