240
Chapter 8 Hardware Configuration/Utilities
8.3.5 Adapter Properties Menu
Sets detailed configuration information on each SCSI adapter.
From the list area on the [Main] menu, select the SCSI adapter to configure.
table: Items on the Adapter Properties Menu
Item Setting Description
Device Properties Configures devices connected to SCSI adapters. Press the [Enter] key to display
the submenu.
ī"8.3.6 Device Properties Submenu" (pg.241)
RAID Properties
Configures or deletes an array.
Synchronize Whole Mirror
The server does not support these items. Do not select these item.
Rebuild
Host SCSI ID 7 (Fixed parameter) Sets the range of host adapter SCSI IDs.
SCSI Bus Scan Order Low to High (0..Max)
(Fixed parameter)
Sets the order of SCSI devices to be scanned during
POST.
Removable Media Support None (Fixed parameter) Sets whether or not to support a removable disk unit
(MO disk unit) as a SCSI disk drive in the SCSI
Setup Utility.
CHS Mapping SCSI Plug and Play
Mapping (Fixed parameter)
Specifies the CHS information mapping method.
Spinup Delay (Secs) 2 (Fixed parameter) Sets device startup intervals.
Secondary Cluster Server No (Fixed parameter) Sets whether or not to use this server in a cluster
configuration.
Termination Control Auto (Fixed parameter) Sets the SCSI bus terminal.
Restore Defaults
The server does not support this.
LSI Logic MPT SCSI Setup Utility Version MPTBIOS-IMx.xx.xx
Esc=Abort/Exit ArrowKeys=Select Item -/+=Change[Item]
Home/End=Select Item Enter=Execute<Item>
<Device Properties>
<RAID Properties> <Synchronize Whole Mirror> <Rebuild>
Host SCSI ID [7]
SCSI Bus Scan Order [Low to High (0..Max)]
Removable Media Support [None]
CHS Mapping [SCSI Plug and Play Mapping]
Spinup Delay (Secs) [2]
Secondary Cluster Server [No]
Termination Control [Auto]
<Restore Defaults>
Adapter
1020/1030
PCI
Bus
3
Dev/
Func
28
Adapter Properties
To Next Page
