Fujitsu PRIMERGY RX200 S2 User Manual

168
Chapter 7 Installing Internal Options
9 Loosen the screw on the rear of the server.
10 Slide the top cover slowly to the rear and lift it to remove from the server.
■ How to Attach the Top Cover
To attach the top cover, simply reverse procedures in "7.2.1 How to Remove the Top Cover" (pg.166).
Notes on installing the server on the rack
 Pull part A on the slide rail (on both sides) toward the front of the slide rail until it stops.
 When sliding the server backward, be sure to keep the slide rails and inner rails on both sides parallel
to each other.
 Check to make sure no tools or unnecessary components were left inside the server before attaching
the top cover back into place.
 When sliding the server backward, press the locks on both sides of the rails to unlock.
 Before turning on the server, make sure that the top cover is attached.
Top cover
Part A
Lock
Slide rail
Inner rail

Fujitsu PRIMERGY RX200 S2 Specifications

General

Chipset	Intel 5000P
Network	Dual Gigabit Ethernet
Operating System Support	Windows Server, Linux
Processor	Intel Xeon processors
Memory Slots	8 x DIMM
RAID Support	RAID 0, 1
Power Supply	Redundant power supply
Form Factor	1U rack server
