U41057-J19-Z146-1-76 July 2004 02–TX150S2–115
Removal/installation routines System board
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k04
Ê Pass the processor fan cable through the retaining clip (see arrow).
Ê Connect to processor fan cable to the connector CPU_FAN1 on the system
board.
The clock frequency of the processor is set automatically. It cannot be
changed manually.
i
