Removal/installation routines Conversion of the housing model
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k04 Ê Screw the rack front panel to the mounting bracket on the left and on the right
side using four countersunk head screws (1). It must be possible for the front
panel to project downwards over the edge of the table.
Ê Screw the two carrier rails onto server at the left and right with three
screws (1).
Ê Mount the server into the rack (description see next chapter).
In order to display the rack server correctly under ServerView, the server type has
to be set:
Ê Insert the ServerStart CD-ROM into the drive.
Ê Call the program SCU_Chassis Model Conversion under
\Tools\System Configuration and change the server type into
"PRIMERGY TX150S2 Rack".
2
1
1
2
1
