U41057-J19-Z146-1-76 July 2004 02–TX150S2–45
Installation and initial operation Settings
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k02
LAN connector
The system board has an Intel 82547EM Gigabit LAN controller. The LAN
controller supports transmission rates of 10 Mbit/s, 100 Mbit/s and 1 Gbit/s. The
LAN controller is equipped with a transmission and receiving buffer (FIFO) and
supports WOL function through Magic Packet
TM
.
It is also possible to boot a device without its own boot hard disk via LAN. Here
Intel PXE is supported.
The LAN RJ45 connector is equipped with a yellow and a green LED (light
emitting diode). This LEDs are integrated into the LAN connector socket.
LED 1 (left)
LED 2 (right)
1 Green indicator 2 Yellow/green indicator
LNK Lights green The adapter is connected to a valid link partner
Off No link
ACT Flashes green Data is being transmitted or received
Off 10 Mbit/s
10/100/1000 Green 100 Mbit/s
Yellow 1000 Mbit/s
12
