Jumper and LEDs
No. Jumper Function
1 BIOSREC This jumper enables recovery of the old system BIOS after an
attempt to update has failed.
1-2 :
2-3 :
(default) the system starts with the BIOS from the system
board.
the system starts from the "Flash BIOS" diskette in drive A
and allows a BIOS recovery.
4
3
2
1
A
DIMM_1B
PCI slot 5
DIMM_0B
PCI slot 4
PCI slot 1
PCI slot 2
PCI slot 3
DIMM_1A DIMM_0A
1
1
1
DIMM0 DIMM1 DIMM2 DIMM3
B
