U41057-J19-Z146-1-76 July 2004 02–TX150S2–65
Installation and initial operation Internal cabling
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k02
Cable overview
The following cables are used in the PRIMERGY TX150S2 systems:
Part number Name Description
Basic cabling
T26139-Y3912-V1 Operating panel cable Connecting operating panel board to
system board (Frontpanel)
T26139 Y3718-V508 I²C bus cable Connecting IDTEMP combo to system
board (SMB1)
T26139-Y3904-V1 USB cable Connecting USB connector on operating
panel board to system board (USB3&4)
T26139-Y3736-V1 Intrusion cable Connecting intrusion switches to system
board (Intrusion)
T26139-Y3728-V1 Fan adapter cable Connecting system fan to system board
(CHA_FAN1)
T26139-Y1248-V8 Floppy disk cable Connecting floppy disk drive to system
board (Floppy)
T26139-Y1737-V111 ATAPI CDROM cable Connecting ATAPI CDROM to IDE1 port
on system board (PRI_IDE)
T26139-Y3785-V301 SCSI cable Connecting internal SCSI drives (acces-
sible drives and SCSI backplane) to
system board (SCSI 320); cabling
onboard SCSI controller or
connecting SCSI backplane to SCSI
controller; cabling add-on SCSI
controller
Option backup SCSI
T26139-Y3859-V11 SCSI cable Connecting SCSI accessible drives to
system board (SCSI 320); cabling add-
on SCSI controller
T26139-Y3576-V209 SCSI cable Connecting SCSI accessible drives to
system board (SCSI 320); cabling add-
on SATA controller
