Fujitsu PRIMERGY TX150 S2 User Manual

02–TX150S2–66 July 2004 U41057-J19-Z146-1-76
Internal cabling Installation and initial operation
Option SATA
T26139-Y3928-V1 SATA cable Connecting SATA backplane to SATA
controller; cabling add-on SATA
controller
SNP:A3C40052661 I²C bus cable SATA Connecting SATA backplane to SATA
controller; cabling add-on SATA
controller
Option add-on controller signalize
T26139-Y2361-V102 Signal cable Connecting controller to system board
(HD-ACTIVITY); signalizing HDD
access to front panel
Option HDD extension box
T26139-Y3927-V1 SCSI cable Connecting HDD extension box to
controller
Option chipDISK
T26139-Y1584-V9 or
T26139-Y1584-V10
IDE cable chipDISK Connecting chipDISK to IDE port on
system board (SEC_IDE)
Option RSBS2
T26139-Y3874-V2 RSBS2 data cable Connecting RSBS2 to system board
(IPMB1)
Part number Name Description
