PRIMERGY TX200 S2 User’s Guide
5
Operations after OS Installation
5.7.7 Jumbo Frame
1000BASE-T/1000BASE-SX supports Jumbo frame. When using Jumbo frame, construct the Jumbo
frame network using only devices that support Jumbo frame and apply the settings that will enable
Jumbo frame.
Configure setting for Jumbo frame according to the following procedures.
1 Start up "Intel(R) PROSet" from [Control Panel].
2 Select a LAN card to perform configuration and click [Advanced] tab.
3 Specify the maximum frame size in [Jumbo Frame] tab.
■ Other Cautions
You cannot connect devices directly with a cross cable without connecting a hub switch or router in
between.
