176
Chapter 7 Installing Hardware Options
7.2 Removing and Attaching Covers
Remove covers to install hardware options. Perform the following procedures to
remove covers.
7.2.1 Removing Covers
1 Turn off the server and connected devices, and unplug all power cables from
the outlet.
2 Slide the drive cover up.
When the drive cover is locked with the drive cover key, unlock the drive cover before sliding it
up.
"1.4.1 Sliding the Drive Cover" (pg.31)
3 Remove the hard disk cover.
Tilt the hard disk cover toward you and pull it up to remove.
• When removing or attaching covers, turn off the server, all peripheral devices,
and any other connected devices. Also unplug all power cables from the
outlet. Failure to do so can cause electric shock ("1.4.4 Turning Off the Server"
(pg.36)).
To Next Page
