Fujitsu PRIMERGY TX200 S2 - Connecting the Server to a PC; Configuring the Terminal Software (PC)

307
PRIMERGY TX200 S2 User’s Guide
Appendix
A
C.2 Connecting the Server to a PC
Connect the server to a PC using an RS-232C cross cable.
C.3 Configuring the Terminal Software (PC)
Perform the settings to enable use of the remote control function using terminal software on the PC.
■ Port Configuration
Configure the port on the PC as follows:
table: Port Settings
Item Contents
Bits/sec. 9600
Data bit 8
Parity Not applied
Stop bit 1
Flow control Not applied
[PC - Rear]
[Server - Rear]
1
Server management port
Serial port
RS-232C cross cable
