196
Chapter 7 Installing Hardware Options
7.5.1 Where to Install an Expansion Card
The server has five PCI slots to accommodate up to five expansion cards.
 The clock frequency depends on the number and specifications of the expansion cards installed.
 Only slot 5 is mounted on the PCI board.
Rear Front
↓Baseboard
PCI slot 5 (32bit33MHz)
PCI slot 4 (64bit133MHz)
PCI slot 3 (64bit133MHz)
PCI slot 2 (64bit100MHz)
PCI slot 1 (64bit100MHz)
