158
Chapter 5 Operations after OS Installation
2 The installer starts up. Proceed the installation by following the window
instructions.
When the window below appears during the installation procedure, check [BASP] and click
[Next].
5.6.2 VLAN Setup Procedure
1 Start up BACS. The procedure differs depending on the OS being used.
For Windows Server 2003
1. Click [Start] → [Control Panel] → [Broadcom Control Suite 2].
For Windows 2000 Server
1. Click [Start] → [Settings] → [Control Panel].
The [Control Panel] window appears.
2. Start up "Broadcom Control Suite 2".
2 Right-click a LAN adapter or the Team name of a Teamed Up adapter and click
[Add VLAN] from the displayed menu.
A LAN adapter is displayed with a mark.
The Team name of a Teamed Up adapter is displayed with a mark.
To Next Page
