Fujitsu PRIMERGY TX200 S2 - How to Install a CPU

183
PRIMERGY TX200 S2 User’s Guide
Installing hardware options
7
7.3.3 How to Install a CPU
1 Turn off the server and connected devices, and unplug all power cables from
the outlet.
2 Remove the side cover
"7.2 Removing and Attaching Covers" (pg.176)
3 Touch a metal part of the server to discharge static electricity.
4 Remove the two ventilation system covers.
5 Remove the CPU cover.
Ventilation system covers
Latch
Latch
