Fujitsu PRIMERGY TX200 S2 User Manual

211
PRIMERGY TX200 S2 User’s Guide
Installing hardware options
7
7.6.3 How to Install the Internal Hard Disk Unit
1 Turn off the server and connected devices, and unplug all power cables from
the outlet.
2 Slide the drive cover up.
When the drive cover is locked, unlock the drive cover before sliding it up.
3 Remove the hard disk cover.
Tilt the hard disk cover toward you and pull it to remove.
4 Touch a metal part of the server to discharge static electricity.
5 Remove the dummy unit from the bay to accommodate an internal hard disk
unit.
Pull the dummy unit out towards you with its tabs being pressed inward.
Be sure to keep the removed dummy units for later use.
Tab s
