174
Chapter 7 Installing Hardware Options
7.1 Before Installing Hardware
Options
The following types of hardware options can be installed in this server.
If devices listed below are optionally purchased, refer to the following to check the packaged items
before installing.
•CPU"B.1 CPU" (pg.302)
• Memory"B.2 Memory" (pg.302)
• Internal Hard Disk Units "B.3 Internal Hard Disk Units" (pg.303)
• Internal hard disk unit bay conversion kit"B.4 Internal Hard Disk Unit Bay Conversion Kit" (pg.303)
When installing and removing options, make sure to use the removed screws on the same devices that
were last installed or removed. Failure to do so can damage the device.
This manual explains how to install hardware options in a pedestal-type server as an example.
The type of optional devices listed in this manual are liable to be updated without any notice. Please be
forewarned.
CPU
Expansion card
Memory
3.5 inch storage bay
(internal hard disk unit)
5 inch storage bay
(internal 5 inch SCSI option)
To Next Page
