PRIMERGY TX200 S2 User’s Guide

Overview

1.4 Standard Operations

This section explains such standard operations as turning the server on/off and

inserting/ejecting CD-ROMs.

1.4.1 Sliding the Drive Cover

1 Turn the drive cover key counterclockwise to unlock the cover.

2 Slide the drive cover.

Slide the drive cover down to use the floppy disk drive, CD-ROM drive, or a 5-inch internal

option device.

 The driver cover key is unique to each device. Do not lose the key. If the key is lost, the lock must be

broken and replaced on a paid basis. Manage the drive cover key very carefully. Refer to "Contact

Information" in "Start Guide", and contact your maintenance engineer if you lose it.

Drive cover key

Drive cover
