180
Chapter 7 Installing Hardware Options
4 Slide the server.
Hold the handles from inside and pull the server out toward you until it clicks, so that it locks in
place on the rails on both sides.
5 Remove the top cover.
The procedures for removing the top cover is the same as that for removing the side cover.
Remove the screws on the rear side. Slowly slide the top cover to the rear side, and then remove
it from the server.
■ Attaching the Top Cover
To attach the top cover, simply reverse the removal procedures.
• Before turning on the server, make sure that all covers are in place.
• Check to make sure no tools or unnecessary components are left inside the
server before attaching the top cover back into place.
Lock
Lock
To Next Page
