3.1 Web MMI
3-8
Navigation
Bar Menu
Menu Contents area Items-1 Items-2 Note
ICCID xxxxxxxxx The number of the SIM card
. Enable
PIN Enable/Disable
. Disable
PIN code . (Xretries left)
Current PIN . (X retries left)
New PIN
.
SIM
Confirm new PIN .
Set up and change the PIN code for the SIM
card.
Note) If the user fails to enter the correct PIN
code for 3 consecutive times, the user
will be required to enter PUK, and the
PIN code is saved in the SIM card.
Basic/GPS
(NMEA port)
Baud rate 4800 bps/38.4 kbps
The setting for Settings -> Basic settings -> GPS
will be displayed.
Port 1
Port 2
Port 3
Basic/ Analog ports
Port 4
Telephone, FAX,
Telephone and fax,
No Connection
The setting for Settings -> Basic settings ->
Analog ports will be displayed.
Ringing pattern Different/Same
Basic/ Incoming
indicator
Enabled service
Voice, FAX, ISDN UDI,
ISDN RDI
The setting for Settings -> Basic settings ->
Incoming indicator will be displayed.
Baud rate
9600, 19200, 38400,
57600, 115200
Parity None, Even, Odd
Basic/ Serial port
Flow control Hardware, Software, None
The setting for Settings -> Basic settings ->
Serial port will be displayed.
IP address 192.168.1.1
Subnet mask 255.255.255.0
Network/LAN
DHCP USE, Unuse
The setting for Settings -> Network settings ->
LAN -> IP address will be displayed.
Settings
Cont’d
Information
Network/WAN Global IP address
The IP address assigned from WAN will be
displayed.
