Furuno FELCOM 250 Service Manual

   
3.1 Web MMI

3-9
Navigation
Bar Menu
Menu Sub Menu Items-1 Items-2 Items-3 Note
Backup GPS (NMEA port)
Baud rate:
4800, 38400 bps
The Baud rate setting for the NMEA port
GPS
GPS monitor
None, Internal GPS, NMEA port
Analog ports 1 Analog ports 2 Analog ports 3
Analog ports
Analog ports 4
Type:
TEL, FAX, TEL and FAX, No Connection
Number:
1000-9999
Note:
-xx
The service setting for the TEL port
Ringing pattern of each service
. Same pattern,
. Different pattern
Incoming indicator
Enable service
. Voice . FAX . ISDN UDI . ISDN RDI
The Ringing setting for the Incoming indicator
Baud rate
9600, 19200, 38400, 57600, 115200
Parity None, Even, Odd
Settings Cont’d
Basic settings Cont’d
Serial port
Flow control
Hardware, Software, None
The setting for the RS-232C port
