Furuno FELCOM 250

Step 2 Reprogramming of Mac Address: when Mac Address is Default
1. Click IP Address in the list, then (d) MAC 変更 box becomes active.
2. Click (d) MAC 変更 .
Enter the MAC Address shown on the LAN module into (f)
新しい MAC アドレス .
(d)
Click IP address
Active
Ver.1.05 update finished
(d)
LAN module
Programmed MAC Address is
shown on the LAN module.
(e)
(f)
6/7
