Furuno FELCOM 250 Service Manual

APPROVED
CHECKED
DRAWN
DWG.NO.
MODEL
UNIT
U49
※ExcludingIMEI‑ROM(U49)
IMEI‑ROM
MJ‑A3SRMD
FELCOM250/500
通信制御ユニット
FB‑2000
COMMUNICATIONUNIT
30Sep.2009 30Sep.2009 30Sep.2009
Y.Kamba T.Yoshida
S.Kubota
1 2
1 1 1 1
4
10
3
▲ ▲
C5666‑E01‑A
ｺｳｻﾞｲ INSTALLATIONMATERIALS CP16‑03811
ｺﾈｸﾀ(N) COAXIALCONNECTOR*NTYPE* N‑P‑8DFB‑CF (000‑156‑918‑10)
+ﾄﾗｽﾀｯﾋﾟﾝﾈｼﾞ1ｼｭ SELFTAPPINGSCREW 5X50SUS304 (000‑170‑987‑10)
ﾋｭｰｽﾞﾊﾘﾏｰｸ FUSELABEL 03‑153‑1312‑0 (100‑292‑140‑10)
ｹｰﾌﾞﾙｶﾅｸﾞ CABLEFIXTURE 16‑021‑2524‑1 (100‑350‑381‑10)
ｱｰｽﾊﾞﾝ COPPERSTRAP 05‑003‑0031‑0 (590‑300‑310‑10)
ｺﾝﾍﾞｯｸｽ CABLETIE CV‑150N (000‑162‑186‑10)
+ﾊﾞｲﾝﾄﾞｾﾑｽF BINDERHEADSCREW‑F M3X8
C2700WMBCR2
(000‑163‑538‑10)
ﾖﾋﾞﾋﾝ SPAREPARTS SP16‑01901
ﾋｭｰｽﾞ GLASSTUBEFUSE FGBO125V15APBF (000‑155‑827‑10)
ﾋｭｰｽﾞ GLASSTUBEFUSE FGBO125V7APBF (000‑155‑831‑10)
CD‑ROM 1650221‑ (001‑069‑710)
ﾀﾞｽﾄｶﾊﾞｰ DUSTCOVER 17‑09SN (000‑156‑324‑10)
ﾀﾞｽﾄｶﾊﾞｰ(RJ‑45) DUSTCOVER DCMJST (000‑168‑520‑10)
ｺﾈｸﾀ CONNECTOR FMC1,5/3‑ST
‑3,5MARK
(000‑170‑889‑10)
ｺﾈｸﾀ CONNECTOR FMC1,5/4‑ST
‑3,5MARK
(000‑170‑890‑10)
ｺﾈｸﾀ CONNECTOR FMC1,5/5‑ST
‑3,5MARK
(000‑170‑891‑10)
ﾎﾟﾘｷｬｯﾌﾟ CAP BNC‑Rﾖｳ (000‑170‑972‑10)
ﾀﾞｽﾄｶﾊﾞｰ(RJ‑11) DUSTCOVER TM‑6‑DC1 (000‑170‑995‑10)
PCB(POWER) 16P0266(LF) (001‑069‑640)
PCB(HUB) 16P0273(LF) (001‑069‑650)
PCB(MODEM) 16P0274A(LF) (001‑069‑660)
PCB(IF) 16P0275(LF) (001‑069‑670)
PCB(PWRC) 16P0276(LF) (001‑069‑680)
PCB(PANEL) 16P0277(LF) (001‑069‑690)
PHCONNECTORASSEMBLY 16‑189(6‑6P) (001‑067‑530)
XHCONNECTORASSEMBLY 16‑192(3‑3P) (001‑067‑560)
XHCONNECTORASSEMBLY 16‑193(8‑8P) (001‑067‑570)
PHCONNECTORASSEMBLY 16‑190(14‑14P) (001‑067‑540)
PHCONNECTORASSEMBLY 16‑188(5‑5P) (001‑067‑520)
ｳｼﾛﾊﾟﾈﾙｸﾐﾋﾝ REARPANELASSEMBLY FB‑2000‑AR‑PANEL (001‑069‑800)
ｳｼﾛﾊﾟﾈﾙ REARPANEL 16‑021‑2514‑2
ｼｰﾙﾄﾞﾊﾟｯｷﾝ(1) SHIELDGASKET(1) 16‑021‑2521‑1
ｼｰﾙﾄﾞﾊﾟｯｷﾝ(3) SHIELDGASKET(3) 16‑021‑2523‑1
ﾏｴﾊﾟﾈﾙｸﾐﾋﾝ FRONTPANELASSEMBLY FB‑2000‑AF‑PANEL (001‑069‑780)
PHｺﾈｸﾀ PHCONNECTORASSEMBLY 16‑190(14‑14P)
ﾏｴﾊﾟﾈﾙ FRONTPANEL 16‑021‑2513‑1
ｶｰﾄﾞﾌﾀ CARDLID 16‑021‑2515‑1 (100‑350‑301‑10)
ｼｰﾙﾄﾞﾊﾟｯｷﾝ(1) SHIELDGASKET(1) 16‑021‑2521‑1
ｼｰﾙﾄﾞﾊﾟｯｷﾝ(2) SHIELDGASKET(2) 16‑021‑2522‑1
PANELﾌﾟﾘﾝﾄ PRINTEDCIRCUITBOARD 16P0277(LF)
SW‑XHｺﾈｸﾀ POWERSWITCHASSEMBLY 16‑191(ｽｲｯﾁ‑2P)
ｹｰｽ(ｳｴ) CASE(UPPER) 16‑021‑2511‑2 (100‑350‑512‑10)
ｹｰｽ(ｼﾀ) CASE(BOTTOM) 16‑021‑2512‑2 (100‑350‑522‑10)
ｹｲｺｸﾗﾍﾞﾙ(1) WARNINGLABEL1 86‑003‑1011‑3 (100‑236‑233‑10)
SW‑XHｺﾈｸﾀ POWERSWITCHASSEMBLY 16‑191(ｽｲｯﾁ‑2P) (001‑069‑820)
+‑ﾅﾍﾞｾﾑｽB WASHERHEADSCREW*B* M3X8
C2700WMBNI2
(000‑163‑190‑10)
+ﾊﾞｲﾝﾄﾞｾﾑｽF BINDERHEADSCREW‑F M4X12SUS304 (000‑163‑912‑10)
ﾁｮｳﾅｯﾄﾅﾐﾋﾝ WINGNUT M4YBSC2 (000‑168‑239‑10)
N M4 (000‑168‑237‑10)
SW M4 (000‑168‑238‑10)
SW M4
PW M4 (000‑168‑235‑10)
PW M4
+ﾅﾍﾞｺﾈｼﾞ PANHEADSCREW M4X20C2700WMBNI2 (000‑163‑439‑10)
ｿﾄﾊTW EXTERNALTOOTHLOCKWASHER M4 (000‑168‑312‑10)
E - 1
