CS875-575-375-275-175 Installers Manual with CS5500 keypad B.6.7
6.5 Glossary
6.6 Technical specifications
6.6.1 CS208 / CS216 input expander
6.6.2 CS208H input expander
Location Term Definition
6 CS208 / CS216 Input Expanders An expander board that increases the number of wired inputs that can be used
for a particular zone. It has an optional tamper switch and a power isolator for
use in a remote location. It cannot be used on the CS175 or CS275 control
panel. The CS208 has 8 zones and the CS216 has 16 zones.
A menu entry that groups CS208/CS216 input expander options.
Power supply specifications
Power supply voltage 13.8V ± 2%
Consumption (with 4K7 EOL) 64 mA at 13.8V ± 2%
Auxiliary Power output 100 mA max at 13.8V ± 2%
General feature specifications
PCB Size Dimensions (width x height x depth) 110x95x25.4 mm
Environmental Operating temperature +0° C to + 40 °C
Humidity Max 93% non condensing
Shipping Weight 115 g
Power supply specifications
Power supply voltage 13.8V ± 2%
Consumption (with 4K7 EOL) 64 mA at 13.8V ± 2%
Auxiliary Power output 100 mA max at 13.8V ± 2%
General feature specifications
PCB Size Dimensions (width x height x depth) 80x60x105 mm
Environmental Operating temperature +0° C to + 40 °C
Humidity Max 93% non condensing
Shipping Weight 105 g
