CS875-575-375-275-175 Installers Manual with CS5500 keypadB.7.9
7.5 Technical specifications
Power supply specifications
Power supply voltage 13.8V ± 2%
Consumption – No outputs active 10 mA at 13.8V ± 2%
Consumption – All outputs active 25 mA at 13.8V ± 2% + current draw of any device
attached.
Auxiliary Power output 100 mA max at 13.8V ± 2%
General feature specifications
PCB Size Dimensions (width x height x depth) 110x95x25.4 mm
Environmental Operating temperature +0° C to + 40 °C
Humidity Max 93% non condensing
Shipping Weight 115 g
