CS875-575-375-275-175 Installers Manual with CS5500 keypadB.3.7
3.9.3 CS5500 menu driven keypad
3.9.4 Keyswitch zones
Power supply specifications
Power supply voltage 13.8V ± 2%
Consumption – Normal condition (Piezo Off) 90 mA at 13.8V ± 2%
Consumption – Normal condition (Piezo On) 100 mA at 13.8V ± 2%
Consumption – Standby 7 mA at 13.8V ± 2%
Consumption – In Alarm 36 mA at 13.8V ± 2%
General feature specifications
PCB Size Dimensions (width x height x depth) 90 x 135 x 1.2
Housing Size Dimensions (width x height x depth) 102x153x29 mm
Environmental Operating temperature +0° C to + 40 °C
Humidity Max 93% non condensing
Shipping Weight 170 g
Static Impulse
Single loop 4k7: Disarmed Quiet
Short Armed Change status
Open: No reaction No reaction
Dual loop 9k4 Disarmed Quiet
4k7 Armed Change status
Short or totally open Tamper Tamper
