CS875-575-375-275-175 Installers Manual with CS5500 keypadB.8.4
8.4 Glossary
8.5 Technical Specifications
Location Term Definition
8 CS586 Direct Connect Module A menu optional device used to interface the up/download software directly to
the control panel when the on board serial port is not available.
8.1 Files A menu entry that groups the four programming memories in the direct connect
module.
8.1.1 File 1 A menu option that selects the programming memories within the direct
connect module. There are four possible programming memories.
8.1.1.1 Panel Type A menu option that displays panel type information currently stored in one of
the four programming memory files in the direct connect module. Possible
values are CS175, CS275, CS375, CS575 and CS875.
8.1.1.2 Panel to File A menu option that copies a panel’s programming to one of the programming
memories in the direct connect module. There are four possible programming
memories in the CS586.
8.1.1.3 File to Panel A menu option to copy programming memory from one of the four memory
locations contained in the direct connect module, to the control panel.
8.2.1 Speed A menu option that sets the data communications speed from the CS586 direct
connect module to the control panel. This can be set from 600 baud to 76.8k
baud. It is recommended to use the default setting of 9600 baud.
Power supply specifications
Power supply voltage 13.8V ± 2%
Consumption 30 mA at 13.8V ± 2%
General feature specifications
Housing Size Dimensions (width x height x depth) 57x100x20 mm
Environmental Operating temperature +0° C to + 40 °C
Humidity Max 93% non condensing
Shipping Weight 150 g
Telephone Telephone requirement Touchtone
To Next Page
